Product Introduction

Product Descriptions


Waterproof start, end, jump connector protective cover

(LK17-BK-CST)

- Product Information

  • Connector protection when installing indoor or outdoor sensors
  • Connect to either end of the sensor
  • Used for connecting sensors as well
  • Corrosion resistance, heat resistance, and good durability
Classification
Specification
Product Name
Waterproof start, end, jump connector protective cover
Model name
LK17-BK-CST
Material
SUS304
Dimensions
95mm(W) X 51.5mm(H) X 12.2mm(D)
Color
SILVER
Usage environment
Can be used in areas handling chemicals such as acids and alkalis
Remarks
All start / end / jump connector
Two jump connectors required

Waterproof corner connector protective cover

(LK17-BK-CCST)

- Product Information

  • Connector protection when installing indoor or outdoor sensors
  • Used to accommodate 90 ° angle when installing sensor
  • Corrosion resistance, heat resistance, and good durability
Classification
Specification
Product Name
Waterproof start, end, jump connector protective cover
Model Name
LK17-BK-CCST
Material
SUS304
Dimensions
111.2mm(W) X 111.2mm(H) X 12.2mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Heat Distortion Temperature
90˚C Reorientation

Explosion-proof start connector protective cover

(LK16-BK-CST-EX-1)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Connect to the sensor
  • Corrosion resistance, heat resistance, and good durability
  • Inherently sturdy explosion-proof layout and accessories included
Classification
Specification
Product Name
Explosion-proof start connector protective cover
Model Name
LK16-BK-CST-EX-1
Material
Casting
Dimensions
70mm(W) X 100mm(H) X 36mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Heat Distortion Temperature
870˚C

Explosion-proof end connector protective cover

(LK16-BK-CST-EX-2)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Connect to the sensor
  • Corrosion resistance, heat resistance, and good durability
  • Inherently sturdy explosion-proof layout and accessories included
Classification
Specification
Product Name
Explosion-proof end connector protective cover
Model Name
LK16-BK-CST-EX-2
Material
Casting
Dimensions
70mm(W) X 65mm(H) X 15mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Heat Distortion Temperature
870˚C

Explosion-proof jump connector protective cover

(LK16-BK-CST-EX-3)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Used to connect sensors at various angles
  • Corrosion resistance, heat resistance, and good durability
  • Inherently sturdy explosion-proof layout and accessories included
Classification
Specification
Product Name
Explosion-proof jump connector protective cover
Model Name
LK16-BK-CST-EX-3
Material
Casting
Dimensions
70mm(W) X 65mm(H) X 15mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Heat Distortion Temperature
870˚C

Explosion-proof corner connector protective cover

(LK16-BK-CST-EX-4)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Used to accommodate 90 ° angle when installing sensor
  • Corrosion resistance, heat resistance, and good durability
  • Inherently sturdy explosion-proof layout and accessories included
Classification
Specification
Product Name
Explosion-proof corner connector protective cover
Model Name
LK16-BK-CST-EX-4
Material
Casting
Dimensions
98mm(W) X 98mm(H) X 19mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Heat Distortion Temperature
870˚C

Multi-leak start, jump connector protective cover

(LK20-BK-SMC)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Connect to the multi-leak flexible sensor
  • Corrosion resistance, heat resistance, and good durability
Classification
Specification
Product Name
Multi-leak start, jump connector protective cover
Model Name
LK20-BK-SMC
Material
SUS304 (1.2T)
Dimensions
135mm(W) X 80mm(H) X 39mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Remarks
Use for indoor protection

Multi-leak end connector protective cover

(LK20-BK-CST)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Connect to the multi-leak flexible sensor
  • Corrosion resistance, heat resistance, and strength
Classification
Specification
Product Name
Multi-leak end connector protective cover
Model Name
LK20-BK-CST
Material
SUS304 (1.2T)
Dimensions
100mm(W) X 51mm(H) X 13mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Remarks
Use for indoor protection

Explosion-proof multi-leak start connector protective cover

(LK20-BK-CST-EX1)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Simple operation by connecting to the multi-leak flexible sensor
  • Corrosion resistance, heat resistance, and good durability
Classification
Specification
Product Name
Explosion-proof multi-leak start connector protective cover
Model Name
LK20-BK-CST-EX1
Material
Die-Casting
Dimensions
75.5mm(W) X 180mm(H) X 38mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Remarks
For protection in hazardous areas

Explosion-proof multi-leak end connector protective cover

(LK20-BK-CST-EX2)

- Product Information

  • Connector protection when installing sensors in hazardous areas
  • Connect to the sensor
  • Corrosion resistance, heat resistance, and good durability
Classification
Specification
Product Name
Explosion-proof multi-leak end connector protective cover
Model Name
LK20-BK-CST-EX2
Material
Die-Casting
Dimensions
75.5mm(W) X 65mm(H) X 16.5mm(D)
Color
SILVER
Usage Environment
Can be used in areas handling chemicals such as acids and alkalis
Remarks
For protection in hazardous areas

Explosion-proof multi-leak corner connector protective cover

(LK20-BK-CST-EX3)
