Product Descriptions
Connectors
Waterproof start, end, jump connector protective cover
(LK17-BK-CST)
- Product Information
Classification | Specification |
Product Name | Waterproof start, end, jump connector protective cover |
Model name | LK17-BK-CST |
Material | SUS304 |
Dimensions | 95mm(W) X 51.5mm(H) X 12.2mm(D) |
Color | SILVER |
Usage environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | All start / end / jump connector Two jump connectors required |
Waterproof corner connector protective cover
(LK17-BK-CCST)
- Product Information
Classification | Specification |
Product Name | Waterproof start, end, jump connector protective cover |
Model Name | LK17-BK-CCST |
Material | SUS304 |
Dimensions | 111.2mm(W) X 111.2mm(H) X 12.2mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Heat Distortion Temperature | 90˚C Reorientation |
Explosion-proof start connector protective cover
(LK16-BK-CST-EX-1)
- Product Information
Classification | Specification |
Product Name | Explosion-proof start connector protective cover |
Model Name | LK16-BK-CST-EX-1 |
Material | SUS304 |
Dimensions | 70mm(W) X 100mm(H) X 36mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Heat Distortion Temperature | 870˚C |
Explosion-proof end connector protective cover
(LK16-BK-CST-EX-2)
- Product Information
Classification | Specification |
Product Name | Explosion-proof end connector protective cover |
Model Name | LK16-BK-CST-EX-2 |
Material | Casting |
Dimensions | 70mm(W) X 65mm(H) X 15mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Heat Distortion Temperature | 870˚C |
Explosion-proof jump connector protective cover
(LK16-BK-CST-EX-3)
- Product Information
Classification | Specification |
Product Name | Explosion-proof jump connector protective cover |
Model Name | LK16-BK-CST-EX-3 |
Material | Casting |
Dimensions | 70mm(W) X 65mm(H) X 15mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Heat Distortion Temperature | 870˚C |
Explosion-proof corner connector protective cover
(LK16-BK-CST-EX-4)
- Product Information
Classification | Specification |
Product Name | Explosion-proof corner connector protective cover |
Model Name | LK16-BK-CST-EX-4 |
Material | Casting |
Dimensions | 98mm(W) X 98mm(H) X 19mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Heat Distortion Temperature | 870˚C |
Multi-leak start, jump connector protective cover
(LK20-BK-SMC)
- Product Information
Classification | Specification |
Product Name | Multi-leak start, jump connector protective cover |
Model Name | LK20-BK-SMC |
Material | SUS304 (1.2T) |
Dimensions | 135mm(W) X 80mm(H) X 39mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | Use for indoor protection |
Multi-leak end connector protective cover
(LK20-BK-CST)
- Product Information
Classification | Specification |
Product Name | Multi-leak end connector protective cover |
Model Name | LK20-BK-CST |
Material | SUS304 (1.2T) |
Dimensions | 100mm(W) X 51mm(H) X 13mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | Use for indoor protection |
Explosion-proof multi-leak start connector protective cover
(LK20-BK-CST-EX1)
- Product Information
Classification | Specification |
Product Name | Explosion-proof multi-leak start connector protective cover |
Model Name | LK20-BK-CST-EX1 |
Material | Die-Casting |
Dimensions | 75.5mm(W) X 180mm(H) X 38mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | For protection in hazardous areas |
Explosion-proof multi-leak end connector protective cover
(LK20-BK-CST-EX2)
- Product Information
Classification | Specification |
Product Name | Explosion-proof multi-leak end connector protective cover |
Model Name | LK20-BK-CST-EX2 |
Material | Die-Casting |
Dimensions | 75.5mm(W) X 65mm(H) X 16.5mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | For protection in hazardous areas |
Explosion-proof multi-leak corner connector protective cover
(LK20-BK-CST-EX3)
- Product Information
Classification | Specification |
Product Name | Explosion-proof multi-leak corner connector protective cover |
Model Name | LK20-BK-CST-EX3 |
Material | Die-Casting |
Dimensions | 75.5mm(W) X 216mm(H) X 29.6mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | For protection in hazardous areas |
Sensor protection cover
(LK19-BK-SUS304)
- Product Information
Classification | Specification |
Product Name | Sensor protection cover |
Model Name | LK19-BK-SUS304 |
Material | SUS304 |
Dimensions | 40mm(W) X 1010mm(H) X 11.2mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | For protection in hazardous areas Fixed the sensor protection cover with the retaining clip |
Sensor protection cover
(LK20-BK-SCP)
- Product Information
Classification | Specification |
Product Name | Sensor protection cover |
Model Name | LK20-BK-SCP |
Material | PC(polycarbonate) |
Dimensions | 60mm(W) X 1000mm(H) X 2mm(D) |
Color | Colorless |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | For protection in hazardous areas |
Sensor retaining clip
(LK12-BK-EXF)
- Product Information
Classification | Specification |
Product Name | Sensor retaining clip |
Model Name | LK12-BK-EXF |
Material | SUS304 |
Dimensions | 58mm(W) X 20mm(H) X 3mm(D) |
Color | SILVER |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | Used to enhance anchoring to outdoor flooring |
Indoor start, end, jump connector protective cover
(LK20-BK-CCP)
- Product Information
Classification | Specification | |
Product Name | Indoor start, end, jump connector protective cover | |
Model Name | LK20-BK-CCP | |
Material | PC(polycarbonate) | |
Dimensions | Upper cover | 95mm(W) X 70mm(H) X 2mm(D) |
Bottom cover | 80mm(W) X 70mm(H) X 13mm(D) | |
Color | Colorless | |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis | |
Remarks | Start / end / jump connector common Two jump connectors required | |
Indoor corner connector protective cover
(LK20-BK-CCCP)
- Product Information
Classification | Specification |
Product Name | Indoor corner connector protective cover |
Model Name | LK20-BK-CCCP |
Material | PC(polycarbonate) |
Dimensions | 113mm(W) X 113mm(H) X 15mm(D) |
Color | Transparent |
Usage Environment | Can be used in areas handling chemicals such as acids and alkalis |
Remarks | Used to enhance anchoring to outdoor flooring |
